N° d'article: 7900400097
DEHNguard MP YPV 1500 FM
surge arrester type II
4 pièces disponible
Merkmale
Profondeur [mm]
66
Largeur [mm]
54
Hauteur [mm]
90
Poids [kg]
0,328
WEEE-Registrier-Nr. DE
11890845
Type de parafoudre
Type II
Côté de raccordement
Côté CC
Description
Surge arrester DEHNguard MP YPV 1500 FM
Multipole, modular, pluggable
Photovoltaic arrester
with double push-in connection terminal suitable for
stub and through-wiring
up to 1500 V DC, width 3TE
Defect indicator
With remote signalling contact
Type 2 according to EN 61643-31
Applicable according to IEC 60364-7-712
Maximum PV voltage: <= 1500 V dc
Total discharge surge current: 40 kA
Protection level: <= 5 kV
Short-circuit withstand voltage Iscpv: 10 kA
Multipole, modular, pluggable
Photovoltaic arrester
with double push-in connection terminal suitable for
stub and through-wiring
up to 1500 V DC, width 3TE
Defect indicator
With remote signalling contact
Type 2 according to EN 61643-31
Applicable according to IEC 60364-7-712
Maximum PV voltage: <= 1500 V dc
Total discharge surge current: 40 kA
Protection level: <= 5 kV
Short-circuit withstand voltage Iscpv: 10 kA
