N° d'article: 5202600002
Huawei LUNA2000-7-E1
Module de batterie 6,9kWh
disponible
Merkmale
Profondeur [mm]
255
Largeur [mm]
590
Hauteur [mm]
360
Poids [kg]
68
capacité énergétique [kWh]
6,8
Profondeur de décharge max. par [%]
100
Type de batterie
Lithium
Tension nominale [V]
600
Batt-Reg.-Nr. DE
82,170,965
WEEE-Registrier-Nr. DE
39372368
Description
Compatible inverters:
SUN2000-2/3/3.68/4/4.6/5/6KTL-L1
SUN2000-8/10K-LC0
SUN2000-3/4/5/6/8/10KTL-M1
SUN2000-5/6/8/10/12K-MAP0
SUN2000-12/15/17/20/25K-MB0
Parallel connection of up to 4 S1 battery towers (MB0 series only) possible.
The LUNA2000 S1 series (6.9kWh) is not compatible with the Luna2000 S0 series (5kWh).
>>> Attention dangerous goods <<<
UN 3480
Lithium-ion battery 9, II (E)
>>>Note the transport data sheet! <<<
SUN2000-2/3/3.68/4/4.6/5/6KTL-L1
SUN2000-8/10K-LC0
SUN2000-3/4/5/6/8/10KTL-M1
SUN2000-5/6/8/10/12K-MAP0
SUN2000-12/15/17/20/25K-MB0
Parallel connection of up to 4 S1 battery towers (MB0 series only) possible.
The LUNA2000 S1 series (6.9kWh) is not compatible with the Luna2000 S0 series (5kWh).
>>> Attention dangerous goods <<<
UN 3480
Lithium-ion battery 9, II (E)
>>>Note the transport data sheet! <<<
