Item No.: 2006400008
AIKO A470-MAH54Dw
bifacial, glas/glas, white, Neostar 2P+
available by week: 28/2026
Merkmale
Length [mm]
1,757
Width [mm]
1,134
Height [mm]
30
Weight [kg]
24,5
Type of DC-connector
EVO2A
max. System Voltage [V]
1,500
Module Efficiency [%]
23,6
Number of cells
108
Cell technology
ABC
Length of connecting cable [m]
1,2
Current value String fuse [A]
25
Color backsheet
WHITE
Frame Colour
BLACK
Product warranty (years)
15
WEEE-Registrier-Nr. DE
52182890
Module design
HALF CELL
Nominal Power [Wp]
470
Max. design load pressure [N/m²]
3,600
Max. design load tension [N/m²]
1,600
Description
The AIKO Axxx-MAH54Dw is a high-performance, double-glazed N-type solar module from the Neostar 2P+ series with a power output of 455–475 Wp and a peak efficiency of up to 23.8%. Thanks to ABC technology (All-Back-Contact), it achieves excellent energy yields and features improved temperature resistance, high wind and snow load capacity (up to 5400 Pa/2400 Pa), and low power loss under low irradiance conditions.
Module TechnologyThe technology is based on the ABC architecture (All-Back-Contact), where all electrical contacts are moved to the rear of the module to fully utilize the active cell area for light absorption, thereby maximizing efficiency. Additionally, the module uses N-type silicon with high temperature stability and low degradation behavior, ensuring a long service life and consistently high energy yields.
QualityAIKO modules stand for the highest quality as they meet strict international certifications such as IEC 61215 and IEC 61730, have been recognized as "Top Performers" in independent tests, and offer exceptional efficiency and longevity through their robust ABC technology. Their resistance to extreme weather conditions, low degradation, and multiple award-winning manufacturing standards make them one of the most reliable solutions in the solar market.
SustainabilityAIKO focuses on the Eco-Design principle across the entire lifecycle of its modules – from material selection and production to packaging and transport, through to use and recycling – and aims for exemplary green manufacturing at its smart Jinan factory through 100% renewable electricity, 90% water recycling, and 30% waste heat utilization. At the same time, the company avoids expensive silver and uses copper-based interconnects, which conserves resources, minimizes thermal stress risk, and improves durability and performance under real-world conditions.
WarrantyThe module offers a 15-year product warranty, which can optionally be extended to 25 years, covering material and manufacturing defects. Additionally, there is a 30-year linear performance warranty, which guarantees a maximum of 1% power loss in the first year and no more than 0.35% per year thereafter.
